Dahua DH-CS4010-8GT-110
10-Port Cloud Managed Gigabit Switch – 8 GE PoE + 2 GE Uplink
| Kategori | Spesifikasi |
|---|---|
| Port / Slot | 8 × RJ-45 10/100/1000 Mbps (PoE) 2 × RJ-45 10/100/1000 Mbps (uplink) 1 × tombol Reset |
| Standar & Protokol | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab |
| PoE / Power | Mendukung IEEE 802.3af, IEEE 802.3at, Hi-PoE, IEEE 802.3bt Port 1–2: hingga 90 W per port Port 3–8: hingga 30 W per port Total PoE budget: ≤ 110 W Fungsi: Intelligent PoE, PoE ON/OFF, Long Distance PoE (250 m), PoE Watchdog |
| Performa | Layer: Layer 2 Switching Capacity: 20 Gbps Packet Forwarding Rate: 14.88 Mpps Packet Buffer: 4 Mbit MAC Address Table: 8K entri VLAN: hingga 32 VLAN Jumbo Frame: hingga 15K bytes |
| Daya & Konsumsi | Power Supply eksternal: 54 V DC, 2.22 A Konsumsi daya idle: ± 3,8 W Konsumsi daya beban penuh: ± 114 W |
| Lingkungan Operasional | Suhu operasi: –10 °C ~ +55 °C Kelembapan operasi: 10% – 90% RH (non-condensing) Suhu penyimpanan: –40 °C ~ +75 °C Kelembapan penyimpanan: 5% – 95% RH |
| Dimensi & Berat | Dimensi produk: 184,6 mm × 103,3 mm × 27 mm (P × L × T) Berat bersih: 0,36 kg (360 g) Berat bruto (kemasan): 1,14 kg Dimensi kemasan: 252 mm × 137 mm × 113 mm |
| Material & Instalasi | Casing: full metal Instalasi: desktop mount / wall mount |
| Proteksi & Keandalan | Proteksi ESD: air discharge 8 kV, contact discharge 6 kV Proteksi petir: common mode 6 kV, differential mode 1 kV Manajemen: Web & Cloud (DoLynk Care) MTBF: ± 2.48 juta jam (~283 tahun) |
