Dahua DH-IPC-HDW2241T-S
2MP IR Fixed-focal Eyeball WizSense Network Camera
Kategori | Spesifikasi |
---|---|
Sensor & Gambar | 1/2.8″ CMOS, progressive scan Resolusi maks: 1920 × 1080 (2MP) @25/30 fps Min. iluminasi: 0.002 lux @F1.6 (Color, 30 IRE); 0.0002 lux @F1.6 (B/W, 30 IRE); 0 lux (IR on) Electronic shutter: Auto/Manual 1/3 s – 1/100,000 s S/N ratio: > 56 dB |
Lensa & Sudut Pandang | Fixed-focal, mount M12; pilihan: 2.8 mm / 3.6 mm; F1.6 FOV 2.8 mm: H 107° × V 56° × D 127° FOV 3.6 mm: H 88° × V 44° × D 105° Close focus: 0.7 m (2.8 mm); 1.3 m (3.6 mm) Pan/Tilt/Rotate: Pan 0–360°; Tilt 0–78°; Rotate 0–360° |
IR / Pencahayaan | IR LED built-in (1 pcs), jangkauan hingga 30 m Kontrol IR: Auto / Manual |
Video & Kompresi | Kompresi: H.265, H.264 (H.264H/H.264B), MJPEG (substream) Smart Codec: Smart H.265+, Smart H.264+ Main stream: 1080p @1–25/30 fps; Sub stream: 704×576 @1–25 fps / 704×480 @1–30 fps Resolusi lain: 1.3M, 720p, D1, VGA, CIF Bitrate control: CBR/VBR; Video bitrate H.264: 32 kbps–6144 kbps; H.265: 12 kbps–6144 kbps Day/Night: Auto (ICR) / Color / B/W |
Fitur Gambar | WDR 120 dB, 3D NR, BLC, HLC ROI (4 area), image rotation 0°/90°/180°/270° White Balance: Auto/Natural/Street Lamp/Outdoor/Manual/Regional custom Gain Control: Auto/Manual, Mirror, Privacy Masking (4 area), Motion Detection (4 area) |
Intelligence (WizSense) | IVS: Intrusion & Tripwire dengan klasifikasi Manusia/Kendaraan Smart Search (kolaborasi dengan Smart NVR) SMD Plus (Smart Motion Detection) |
Audio & Alarm | Built-in Mic; Audio codec: G.711a, G.711µ, PCM, G.726 Event: No SD card / SD full / SD error, network disconnect, IP conflict, illegal access, motion, video tampering, tripwire, intrusion, SMD, voltage detection, security exception |
Jaringan | 1 × RJ-45 (10/100 Base-T); ONVIF Profile S/G/T, CGI; SDK/API Protokol: IPv4/IPv6, HTTP, TCP, UDP, ARP, RTP/RTSP/RTCP/RTMP, SMTP, FTP/SFTP, DHCP, DNS/DDNS, NTP, Multicast, ICMP, IGMP, P2P User/Host: hingga 6 pengguna (36 Mbps total) |
Penyimpanan | Micro SD/SDHC/SDXC hingga 256 GB; FTP & SFTP |
Daya | 12 VDC / PoE (802.3af) Konsumsi: Basic 2.1 W (12 VDC) / 2.4 W (PoE); Maks 4.2 W (12 VDC) / 5.1 W (PoE) |
Lingkungan & Proteksi | Suhu operasi: –40 °C ~ +60 °C; Kelembapan ≤ 95% RH (non-condensing) Proteksi: IP67 |
Dimensi & Berat | Dimensi produk: 10.09 cm × Ø 10.99 cm (P × Diameter) Berat bersih: ± 0.37 kg; Berat bruto: ± 0.56 kg Material: Inner core metal; cover plastik |
Isi dalam Box | 1 × Kamera DH-IPC-HDW2241T-S Bracket/dudukan bawaan Sekrup & fisher Quick Start Guide & kartu garansi Waterproof cable cap / rubber plug |
