HIK-IC2449OUT
4MP Outdoor Warm Light Network Camera (WizView Series)
| Kategori | Detail |
|---|---|
| Kamera | Sensor: 1/1.8″ CMOS Resolusi Maks: 2688 × 1520 (4MP) ROM: 128 MB • RAM: 256 MB Sistem Pemindaian: Progressive Shutter: Auto/Manual (1/3 s–1/100,000 s) Min. Illumination: 0.0005 Lux @ F1.0 S/N Ratio: > 56 dB Illuminator: Warm Light hingga 50 m (4 unit), Auto/Manual |
| Lensa | Tipe: Fixed-focal (3.6 mm & 6 mm) Aperture: F1.0 FOV 3.6 mm: H 83°, V 45°, D 97° FOV 6 mm: H 53°, V 31°, D 61° Mount: M16 Close Focus: 3.6 mm (2.6 m), 6 mm (5.4 m) DORI 3.6 mm: Detect 70.3 m • Observe 28.1 m • Recognize 14.1 m • Identify 7 m DORI 6 mm: Detect 120.6 m • Observe 48.2 m • Recognize 24.1 m • Identify 12 m |
| Video | Frame Rate: 4MP @ 1–25/30 fps, 1440p @ 1–25/30 fps Stream: 2 streams (Main + Sub) Resolusi Tambahan: 3MP, 1080p, 720p, VGA, CIF Bit Rate: H.264: 32–6144 kbps • H.265: 12–6144 kbps Day/Night: Color/B/W Fitur: BLC, HLC, WDR 120 dB, 3D NR, Smart Illumination, ROI (4 area), Privacy Masking (4 area), LDC, Mirror, Image Rotation |
| Audio | Mikrofon Bawaan: Ya Kompresi Audio: G.711a, G.711Mu, PCM, G.726 |
| Alarm & Analitik | IVS: Intrusion, Tripwire (klasifikasi manusia/kendaraan) SMD Plus Deteksi Abnormal: motion, tamper, audio, SD error/full, network disconnect, IP conflict, illegal access, voltage detection |
| Jaringan | Port: RJ-45 (10/100 Base-T) Protokol: IPv4, IPv6, HTTP, HTTPS, TCP/IP, UDP, ARP, RTP, RTSP, RTCP, SMTP, NTP, DHCP, DNS, DDNS, FTP, SFTP, QoS, UPnP, Multicast, IGMP, SNMP, NFS, PPPoE, Bonjour, Auto Register ONVIF: Profile S, G, T |
| Umum | Penyimpanan: Micro SD (maks. 256 GB), NAS, FTP, SFTP Daya: 12 VDC ±30% / PoE (802.3af), maks. 9.1 W Proteksi: IP67 Suhu Operasi: -40°C hingga 60°C Kelembapan: ≤ 95% (non-condensing) |
