HiView IPC-B20
2MP IR Fixed-focal Bullet Network Camera
| Kategori | Detail |
|---|---|
| Kamera | Image Sensor: 1/3.2″ CMOS Resolusi Maks.: 1920 × 1080 (2MP) ROM: 16 MB • RAM: 64 MB Sistem Pindai: Progressive Shutter: 1/3 s – 1/100,000 s (Auto/Manual) Min. Illumination: 0.01 Lux (warna, 30 IRE), 0.005 Lux (B/W, 30 IRE), 0 Lux (IR ON) S/N Ratio: ≥ 56 dB Jarak IR: hingga 30 m (2 × IR LED) Mode IR: Auto/Manual Penyesuaian Sudut: Pan 0–360°, Tilt 0–90°, Rotate 0–360° |
| Lensa | Jenis: Fixed-focal • Mount: M12 Focal Length: 2.8 mm / 3.6 mm Aperture: F2.2 FOV 2.8 mm: H 99°, V 53°, D 117° FOV 3.6 mm: H 79°, V 43°, D 94° Close Focus: 0.5 m (2.8 mm) • 0.8 m (3.6 mm) |
| DORI | 2.8 mm: Deteksi 44.7 m • Observasi 17.9 m • Rekognisi 8.9 m • Identifikasi 4.5 m 3.6 mm: Deteksi 55.0 m • Observasi 22.0 m • Rekognisi 11.0 m • Identifikasi 5.5 m |
| Video | Kompresi: H.265, H.264, MJPEG Smart Codec: Smart H.265+, Smart H.264+ Resolusi: 1080p, 1.3M, 720p, D1, CIF Frame Rate: 1080p@25/30 fps (Main); D1/CIF@25/30 fps (Sub) Stream: 2 streams Bit Rate: H.264: 32–4096 Kbps • H.265: 12–4096 Kbps ROI: 4 area • WDR: DWDR Fitur: BLC, HLC, 3D NR, White Balance Auto, Gain Control Auto |
| Alarm & Jaringan | Event: Network disconnection, IP conflict, illegal access, motion detection, video tampering, security exception Port: RJ45 (10/100 Base-T) Protokol: IPv4/IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, SMTP, FTP, DHCP, DNS, NTP, Multicast, P2P Interoperabilitas: ONVIF (Profile S, T) User: hingga 6 channel (24 M total) Penyimpanan: FTP Browser: IE, Chrome, Firefox Software: Hiview Connect Mobile: iOS, Android |
| Keamanan Siber | Fitur: Password protection, encryption, trusted boot, certificate management, video encryption |
| Daya & Lingkungan | Power: 12 VDC / PoE Konsumsi: Basic 1.2 W, Max 2.8 W (IR ON) Suhu Operasi: −40°C hingga 50°C Kelembapan: ≤ 95% (non-condensing) Proteksi: IP67 |
| Fisik | Material: Plastik Dimensi: 198.9 × 80.2 × 76.2 mm Berat Bersih: 0.25 kg • Berat Kotor: 0.37 kg |
