TC-H324S 2MP PTZ 23X Optical Zoom
TC-H324S 2MP PTZ 23X Optical Zoom - Gambar 2
TC-H324S 2MP PTZ 23X Optical Zoom - Gambar 3
TC-H324S 2MP PTZ 23X Optical Zoom - Gambar 4

TC-H324S 2MP PTZ 23X Optical Zoom

Rp3.499.000

Tiandy TC-H324S (23X)

2 MP Starlight IR PTZ Camera • 23× Optical Zoom

  • Sensor 1/2.8″ Starlight CMOS
  • Resolusi 1920 × 1080 @ 30 fps (Full HD)
  • 23× Optical Zoom • kecepatan pan/tilt: 0.1° ~ 80°/s
  • 120 dB WDR • Low Lux 0.001 Lux
  • IR hingga 150 m (Smart IR)
  • Proteksi petir TVS 6000V
  • Penyimpanan lokal: microSD hingga 512 GB
  • AI Detection: Human / Vehicle classification
  • Kompatibilitas: ONVIF Profile S/T/G/M
  • Housing Aluminum + Plastic, tahan cuaca IP66
  • Bracket sudah termasuk (tanpa adaptor daya)

2 MP 1080p
23× Zoom
IR 150 m
120 dB WDR
AI Human/Vehicle
IP66
PoE / DC12V

Hubungi Admin
Kategori: Tag: Brand:
Post Views: 26

Tiandy TC-H324S

2 MP 23× IR PTZ Starlight Camera

Kategori Detail
Model TC-H324S — Spec: 23X/I/E/C/V3.0
Kamera & Video Sensor: 1/2.8″ Starlight CMOS
Resolusi: 1920 × 1080 @ 30 fps
Min. Illuminasi: 0.001 Lux (warna) • 0 Lux (IR ON)
WDR: 120 dB
S/N Ratio: > 42 dB
Lensa & Zoom Lensa: Vari-Focal 4.7 – 108.1 mm (23× Optical Zoom)
Aperture: F1.6 ~ F3.5 • Iris Auto
FOV: H 58.3° ~ 3.2° • V 34.5° ~ 1.8° • D 67.1° ~ 3.6°
Fokus: Auto / Manual • Jarak Fokus Min.: 100 mm (wide) ~ 1000 mm (tele)
PTZ Pan: 360° (endless) • Tilt: –20° ~ 90° (Auto Flip 180°)
Kecepatan Pan/Tilt: 0.1° ~ 80°/s
Preset: 256 posisi • Patrol: 16 (dengan max. 32 preset)
Pattern: 4 jalur • Auto Scan: tersedia
IR & Audio IR LED: jarak hingga 150 m (850 nm, Smart IR)
Audio: Built-in Mic
Kompresi & Streaming Video: S+265 / H.265 / H.264
Bitrate: 32 kbps ~ 16 Mbps
Main Stream: 1080p @ 30 fps
Sub Stream: D1 / CIF @ 30 fps
Fitur: BLC / HLC / 3D DNR / Defog / ROI / Privacy Mask
AI & Analitik Human / Vehicle Classification
Smart Detection: Tripwire, Intrusion, Region Entrance/Exit
Jaringan & Kompatibilitas Protokol: HTTP, HTTPS, TCP/IP, UDP, RTSP, DHCP, DNS, DDNS, NTP, FTP, IPv4, QoS, dll.
Kompatibilitas: ONVIF Profile S/T/G/M
Client: Easy7 VMS • Mobile: EasyLive Plus
Penyimpanan Slot microSD hingga 512 GB
Mendukung NAS, FTP, dan Edge Storage
Lingkungan & Proteksi Operasional: –30 °C ~ +60 °C, RH ≤ 95% (non-condensing)
Proteksi: IP66 • TVS 6000 V Surge Protection
Daya Input: DC12V ±25% / PoE+ (IEEE 802.3at, max 18 W)
Dimensi & Berat Dimensi Kamera: Φ160 × 295 mm
Dimensi Paket: 370 × 250 × 200 mm
Berat: 3.9 kg (dengan bracket)
Paket Kamera PTZ TC-H324S + Bracket bawaan
(Adaptor daya tidak termasuk)

Informasi Tambahan

Berat 3900 gram
Dimensi 370 × 250 × 200 cm
