Dahua DH-XVR5104HS-4KL-I3 (V3)
4CH Penta-brid 4K/5MP Compact 1U DVR – WizSense Series
| Kategori | Spesifikasi |
|---|---|
| Sistem & Umum | Prosesor industrial-grade • OS: Embedded Linux • Interface: Web & GUI lokal |
| AI & Fitur Cerdas | QuickPick 2.0 (2 kanal untuk analog) Privacy Protection (1 kanal – masking wajah real time) SMD Plus: 4 kanal (analog) atau 8 kanal by camera Perimeter Protection: 4 kanal (tripwire & intrusion) Face Recognition: 2 kanal (analog) – face comparison AI Coding: 4 kanal (penghematan bandwidth/penyimpanan) AI Video Quality Analytics (brightness, color cast, defocus, overexposure, contrast, BW) – 4 kanal Scene Changing: 1 kanal • Irregular Black Block Masking: 1 kanal • EPTZ: 1 kanal |
| Video / Audio | Input analog: 4 × BNC (HDCVI / AHD / TVI / CVBS auto-detect) Input IP: hingga 8 channel (4 default + 4 konversi), masing-masing hingga 8 MP Bandwidth masuk / rekaman / keluar: hingga 64 Mbps Output: 1 × HDMI (hingga 3840×2160) + 1 × VGA Audio: 1 × RCA In, 1 × RCA Out + audio over coax (4 kanal) Two-way Talk: Ya (audio input berbagi kanal 1) |
| Kompresi & Streaming | AI Coding, Smart H.265+, H.265, Smart H.264+, H.264 Dual-stream: Ya Bitrate video configurable: 32 kbps – 6144 kbps |
| Rekaman & Playback | Mode rekaman: General, Alarm, Motion, Intelligent, POS Playback: 1/4 layar; Instant, Event, Tag, Smart, General modes Backup: USB device & jaringan |
| Alarm & Linkage | Alarm: Motion detection, external, HDCVI alarm, video loss, tampering, disk error, network alarm, etc Tindakan: rekam, snapshot, preset, email, buzzer, log, IPC alarm output, audio |
| Port & Antarmuka | 1 × SATA (hingga 16 TB) 2 × USB 2.0 (1 depan, 1 belakang) 1 × RS-485 (PTZ control) 1 × RJ-45 (10/100 Mbps) 1 × HDMI + 1 × VGA |
| Daya & Lingkungan | 12 V DC, 2 A Konsumsi: < 7 W (tanpa HDD) Suhu Operasi: –10 °C hingga +55 °C Penyimpanan: –20 °C hingga +60 °C Kelembapan: 10% – 90% RH (non-condensing) |
| Dimensi & Berat | 260.0 mm × 237.8 mm × 47.6 mm (W × D × H) Berat bersih: 0.96 kg Berat kotor (paket): 1.37 kg |
| Sertifikasi & Standar | CE, FCC, EN 62368-1, EN 55032, EN 55024, EN 55035, EN 61000 series Instalasi: desktop / rak |
